Airtac F-GS Pressure Gauge F-GS4004M
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS4004M Pressure Gauge Technical Details
- Model: F-GS4004M
- Type: Bourdon tube pressure gauge with glycerin damping
- Pressure range: 0-1.6 MPa (customizable up to 60 MPa)
- Accuracy class: ±2.5% F.S. (ASME B40.1 Grade B)
- Connection size: G1/4" BSPP (NPT1/4" optional)
- Case material: Stainless steel SS304 with baked enamel finish
- Window: Polycarbonate lens (5mm thickness)
- Fill fluid: Glycerin (98% purity, frost-resistant)
- Temperature limits:
- Ambient: -20℃ to 60℃
- Medium: -20℃ to 80℃
- Vibration resistance: ≤2.5mm amplitude at 10-55Hz
- Weight: 480g ±5% (with mounting bracket)
- Dimensions: 80mm diameter × 65mm depth (excluding stem)
- Mounting: Bottom entry with 30mm adjustable stem
- IP rating: IP54 (splash and dust resistant)
Industrial-grade pressure measurement instrument featuring shock-absorbing liquid filling for stable needle movement in high-vibration environments. The stainless steel case withstands corrosive atmospheres, while the oversized dial (55mm visible scale) ensures clear visibility in low-light conditions. Includes a calibration mark slot for maintenance records.
- Hydraulic power unit pressure monitoring
- Compressed air system diagnostics
- Plastic injection molding machines
- CNC equipment lubrication systems
- HVAC refrigerant pressure checks
Installation guidelines:
Mount vertically ±5° to prevent fluid leakage. Use thread seal tape on male connections.
Avoid direct sunlight exposure to prevent glycerin discoloration. Perform zero-point
calibration every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | F-GS4004M |
| Port Size | PT1/8 |
