Airtac F-GS Pressure Gauge F-GS4004P
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS4004P Pressure Gauge Technical Specifications
- Model: F-GS4004P
- Type: Direct-mounted pressure gauge with vibration dampening
- Pressure range: 0-1.6 MPa (0-232 PSI)
- Accuracy class: ±2.5% F.S. (ASME B40.1 Grade B)
- Port connection: G1/4 female thread (BSPP standard)
- Dial diameter: 63mm (2.5")
- Case material: Stainless steel SS304 housing
- Diaphragm: NBR membrane with copper alloy movement
- Temperature limits:
- Operating: -20℃ to 80℃
- Storage: -30℃ to 85℃
- Weight: 320g ±5% (including fittings)
- Dimensions: 63mm(D) × 80mm(H) × 50mm(installation length)
- Protection rating: IP54 (dust protected & water splashed resistant)
- Pressure medium compatibility: Air, non-corrosive gases
- Max momentary pressure: 2.4 MPa (348 PSI)
Industrial-grade pressure gauge featuring shock-resistant construction with liquid-filled option (optional suffix "-L"). The glycerin-filled version minimizes pointer oscillation in high-vibration environments. Features a 270° scale rotation capability for flexible installation alignment.
- Pneumatic compressor system monitoring
- Injection molding machine pressure verification
- CNC machine air circuit diagnostics
- Industrial vacuum system balancing
- Hydraulic test bench calibration (when compatible with medium)
Installation guidelines:
Mount vertically with port facing downward to prevent media accumulation.
Use thread seal tape on male connections. Avoid direct sunlight exposure
and maintain 100mm clearance from heat sources. Perform monthly zero-point
calibration under depressurized conditions.
| Property | Property Value |
|---|---|
| sku | F-GS4004P |
| Port Size | PT1/8 |
