Airtac F-GS Pressure Gauge F-GS4010B
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS4010B Pressure Gauge Technical Details
- Model: F-GS4010B
- Type: Bourdon tube pressure gauge with glycerin-filled dampening
- Pressure range: 0-1.0 MPa (0-145 PSI dual scale)
- Accuracy class: ±2.5% F.S. (ASME B40.100 Grade B)
- Connection: 1/4" NPT male thread (G1/4 optional)
- Dial diameter: 60mm (2.36")
- Case material: Stainless steel SS304 with polycarbonate window
- Seal material: Viton FKM
- Operating temperature: -20℃ to 60℃ (-4°F to 140°F)
- Filling fluid: Glycerin (98% purity, viscosity 1000cSt)
- Weight: ~200g (0.44 lbs)
- Dimensions: 60mm diameter × 70mm height
- Mounting depth: 15mm
- Protection rating: IP65 (front face), IP54 (overall)
- Overpressure safety: 130% of full scale
Industrial-grade vibration-resistant pressure gauge featuring shock-absorbing liquid filling and anti-parallax dial design. The stainless steel case withstands harsh environments while the oversized scale markings (5mm height) enable quick readings. Includes a zero-adjustment screw and dual-scale calibration for flexible monitoring.
- Pneumatic system pressure monitoring in assembly lines
- Hydraulic power unit pressure verification
- HVAC refrigerant pressure checks
- Water treatment plant pump systems
- Industrial machinery preventive maintenance
Installation guidelines:
Mount vertically within ±5° angle deviation. Use thread seal tape on connections.
Avoid direct sunlight exposure to prevent glycerin discoloration.
Calibrate quarterly under static pressure conditions.
| Property | Property Value |
|---|---|
| sku | F-GS4010B |
| Port Size | PT1/8 |
