Airtac F-GS Pressure Gauge F-GS4010M
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS4010M Pressure Gauge Technical Specifications
- Model: F-GS4010M
- Type: Bourdon tube pressure gauge with mechanical display
- Pressure range: 0-1.0 MPa (customizable to 0-1.6 MPa)
- Accuracy class: ±2.5% F.S. (Grade 2.5)
- Connection size: G1/4" BSPP female thread
- Dial diameter: 50mm (2")
- Case material: Stainless steel SS304
- Window material: Polycarbonate (impact-resistant)
- Movement material: Brass alloy C3771
- Temperature limits:
- Operating: -20℃ to +60℃
- Storage: -30℃ to +70℃
- Pressure medium: Compatible with air, non-corrosive gases
- Weight: 298g ±5g (without packaging)
- Dimensions: 80mm (Ø) × 60mm (H) × 35mm (mounting depth)
- Protection rating: IP54 (splash/dust resistant)
- Vibration resistance: ≤25Hz with 1.5mm amplitude
- Certifications: CE, RoHS compliant
Industrial-grade pressure measurement instrument featuring shock-absorbing liquid filling (optional glycerin fill for pulsation damping). The 270° scale rotation allows flexible mounting orientations. Features a zero-point adjustment screw and overpressure protection (130% of full scale).
- Pneumatic system pressure monitoring in CNC machines
- Compressed air line pressure verification
- Hydraulic system auxiliary monitoring (with compatible fluids)
- Industrial boiler auxiliary pressure indication
- Packaging machinery pressure regulation systems
Installation guidelines:
Use PTFE tape on threads for sealing. Mount vertically within ±15° deviation.
Avoid direct sunlight exposure and install shock absorbers in high-vibration environments.
Bleed air slowly during initial pressurization.
| Property | Property Value |
|---|---|
| sku | F-GS4010M |
| Port Size | PT1/8 |
