Airtac F-GS Pressure Gauge F-GS4010P
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS4010P Pressure Gauge Technical Specifications
- Model: F-GS4010P
- Measurement Range: 0-1.0 MPa (0-10 bar / 0-145 psi)
- Accuracy Class: ±2.5% F.S. (EN 837-1 standard)
- Connection Type: G1/4" BSPP male thread (stainless steel)
- Dial Size: 40mm diameter
- Case Material: Black powder-coated steel case
- Window: Laminated safety glass
- Movement: Brass bourdon tube mechanism
- Liquid Filling: Glycerin-filled (95% volume)
- Temperature Limits:
- Ambient: -20°C to +60°C
- Medium: Max +70°C (non-condensing)
- Pressure Unit Markings: Dual scale (MPa & psi)
- Mounting: Rear flush diaphragm with anti-vibration pad
- Weight: 320g ±5% (including packaging)
- Dimensions: 54mm(W) × 54mm(H) × 40mm(D)
- IP Rating: IP54 (dust and water splash resistant)
- Calibration: Factory pre-calibrated with NIST traceability
Industrial-grade pressure gauge featuring shock-resistant construction and temperature-compensated movement. The glycerin filling dampens pointer oscillation in high-vibration environments. Stainless steel internals ensure compatibility with compressed air, inert gases, and non-corrosive hydraulic fluids (ISO VG 32-68).
- Pneumatic system pressure monitoring in CNC machinery
- Hydraulic power pack pressure verification
- Compressed air distribution line diagnostics
- Industrial boiler auxiliary pressure indication
- Plastic injection molding machine pressure feedback
Installation Guidelines:
Use PTFE tape on threads and tighten to 12-15 N·m torque.
Maintain vertical orientation (±5° tolerance). Avoid direct sunlight exposure
and install below process connections to prevent fluid accumulation.
Perform zero-point calibration every 2,000 operating hours.
Not compatible with oxygen systems or aggressive chemicals.
Maximum pressure spikes must not exceed 120% of full scale.
Drain condensate regularly when monitoring humid air systems.
| Property | Property Value |
|---|---|
| sku | F-GS4010P |
| Port Size | PT1/8 |
