Airtac F-GS Pressure Gauge F-GS4010Z
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS4010Z Pressure Gauge Technical Details
- Model: F-GS4010Z
- Series: F-GS (General Service)
- Pressure range: 0.1-1.0 MPa / 14.5-145 psi (standard), 0-1.6 MPa optional
- Accuracy class: ±2.5% F.S. (full scale)
- Port connection: G1/4 female thread (ISO228-1 standard)
- Dial diameter: 60mm ±0.5mm
- Case material: Black phenolic resin with tempered glass
- Movement material: Brass (nickel-plated internals)
- Liquid-filled: Glycerin-filled (standard), dry gauge available
- Operating temp: -5℃ to 60℃ (medium temp: ≤80℃)
- Weight: ~200g (without accessories)
- Dimensions: Ø60mm × 80mm(H) (body), 45mm mounting depth
- IP rating: IP54 (splash/dust resistant)
- Vibration resistance: ≤3g acceleration (10-55Hz)
Rugged industrial pressure gauge with shock-absorbing snubber, featuring 270° rotation-adjustable bezel for optimal viewing angles. The glycerin-filled design dampens pointer oscillation in high-vibration environments. Calibration marks include dual MPa (black) and psi (red) scales with laser-etched graduations.
- Air compressor pressure monitoring systems
- Pneumatic tool line pressure regulation
- Hydraulic power unit diagnostics
- HVAC refrigerant pressure tracking
- Industrial machinery lubrication circuits
Installation guidelines:
Mount vertically ±5° using the rear 1/4"NPT mounting boss.
Use thread sealant on connections and avoid side-loading.
For pulsating systems, install pulsation damper upstream.
Zero calibration required after 5,000 operating hours.
| Property | Property Value |
|---|---|
| sku | F-GS4010Z |
| Port Size | PT1/8 |
