Airtac F-GS Pressure Gauge F-GS5004B
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS Pressure Gauge F-GS5004B Technical Details
- Model: F-GS5004B
- Type: Bourdon tube pressure gauge (mechanical)
- Measurement range: 0-1.6 MPa (0-16 bar / 0-232 psi)
- Accuracy class: 1.6 (EN 837-1 standard)
- Connection size: G1/4" (BSPP female thread)
- Case material: Stainless steel SS304 with polycarbonate window
- Movement material: Brass alloy C3771
- Temperature limits:
- Ambient: -20℃ to +60℃
- Media: -20℃ to +80℃ (dry air only)
- Pressure unit display: Dual scale bar/psi (switchable)
- Mounting: Panel installation with 55mm cutout
- Protection: IP54 (front side), IP42 (rear)
- Vibration resistance: ≤25m/s² (3-55Hz frequency range)
- Weight: 250g ±5% (excluding packaging)
- Dimensions: 60mm(W) × 60mm(H) × 48mm(D)
Industrial-grade pressure measurement instrument with shock-absorbing structure and glycerin-filled option (F-GS5004B-G variant). Features 270° scale rotation capability for flexible installation orientations. The stainless steel case withstands industrial contaminants, while the 6mm thick safety glass prevents fogging.
- Pneumatic system pressure monitoring in CNC machines
- Compressed air line diagnostics in automotive workshops
- Hydraulic pressure verification (with compatible adapters)
- Process control in plastic injection molding equipment
- Energy management systems for air compressor stations
Installation guidelines:
Use 1.5-2Nm torque for connection tightening. Avoid direct sunlight exposure
to prevent polycarbonate yellowing. For pulsating media applications,
specify "-G" glycerin-filled version (F-GS5004B-G). Calibrate annually
under 25±5℃ ambient temperature.
| Property | Property Value |
|---|---|
| sku | F-GS5004B |
| Port Size | PT1/4 |
