Airtac F-GS Pressure Gauge F-GS5004Z
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS5004Z Pressure Gauge Technical Details
- Model: F-GS5004Z
- Type: Bourdon tube pressure gauge with glycerin-filled dampening
- Measurement range: 0-1.0 MPa (0-145 psi / 0-10 bar)
- Accuracy class: ±1.6% full scale (EN 837-1 standard)
- Connection size: G1/4" female thread (BSPP)
- Case material: 304 stainless steel with epoxy coating
- Window material: 3mm thick polycarbonate
- Operating temperature: -20°C to +60°C (-4°F to 140°F)
- Weight: 280g ±5g (with packaging)
- Dimensions: 60mm diameter × 45mm depth (body only)
- Mounting orientation: Radial (stem-mounted) configuration
- Scale divisions: 0.05 MPa increments
- Overpressure protection: 130% of full scale for 1 minute
- Vibration resistance: Up to 25m/s² at 10-150Hz
- IP rating: IP54 (dust and splash resistant)
Industrial-grade pressure gauge featuring shock-absorbing glycerin fill that minimizes needle flutter in high-vibration environments. The stainless steel housing and corrosion-resistant internals make it suitable for compressed air systems, hydraulic monitoring, and pneumatic tool applications. Calibrated for both bar and psi scales with dual-color (black on white) dial for enhanced readability.
- Air compressor output monitoring
- CNC machine pneumatic circuit diagnostics
- Hydraulic power pack pressure verification
- Industrial boiler safety systems
- Plastic injection molding machines
Mounting advice:
Install using 10mm open-end wrench on hex base - do not overtighten (max 15N·m torque).
Maintain vertical orientation (±5° tolerance) for optimal accuracy. Avoid direct sunlight exposure
to prevent glycerin discoloration.
| Property | Property Value |
|---|---|
| sku | F-GS5004Z |
| Port Size | PT1/4 |
