Airtac F-GS Pressure Gauge F-GS5010M
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS5010M Pressure Gauge Technical Specifications
- Model: F-GS5010M
- Type: Bourdon tube pressure gauge with dampening mechanism
- Pressure range: 0-1.0 MPa (0-10 bar / 0-145 psi)
- Accuracy class: ±2.5% full scale (EN 837-1 standard)
- Connection size: G1/4" BSPP female thread
- Connection position: Radial (bottom entry)
- Case material: Stainless steel SS304 with powder coating
- Window material: Shatter-resistant polycarbonate (PC)
- Dial diameter: 60mm (2.36")
- Movement material: Phosphor bronze bourdon tube & brass socket
- Temperature limits:
- Ambient: -20°C to 60°C
- Media: Max 80°C for continuous operation
- Pressure medium: Compatible with air, oil, water (non-corrosive gases/liquids)
- IP rating: IP54 (dust protected, water splashes)
- Weight: 300g ±5% (including packaging)
- Dimensions: 60mm diameter × 80mm height
- Mounting depth: 50mm from back case to tip of connection
Industrial-grade pressure measurement instrument featuring anti-vibration liquid filling (glycerin) for stable needle indication in pulsating environments. The chrome-plated brass connection resists corrosion while the 270° scale rotation allows flexible mounting alignment. Includes a zero-adjustment screw and safety blow-out back design.
- Pneumatic system pressure monitoring in automation lines
- Hydraulic power pack pressure verification
- Compressed air receiver tank safety checks
- Industrial chillers and HVAC refrigerant pressure tracking
- CNC machine lubrication system monitoring
Installation guidelines:
Mount vertically with connection port downward. Use thread sealant on male connections.
Avoid installation near heat sources or excessive vibration points.
For pulsating systems, pair with a snubber valve (sold separately).
Calibrate annually under 25°C ambient conditions.
| Property | Property Value |
|---|---|
| sku | F-GS5010M |
| Port Size | PT1/4 |
