Airtac F-HFCQ-V Spring-Type Push Rod Finished Product Kit F-HFCQ32V
Category: Cylinder Accessories
Brand: AIRTAC
Precision-engineered spring return mechanism with corrosion-resistant plating
Integrated modular design for direct cylinder mounting compatibility
Pre-lubricated components ensuring smooth stroke operation
Standardized interfaces compliant with ISO 6431/6432 pneumatic cylinder specifications
Technical features:
- Double-acting stainless steel return spring
- Hardened guide rod with ±0.01mm concentricity tolerance
- High-cycle PTFE wear-resistant seals
- Ambient temperature range: -10°C to +80°C
AirTAC F-HFCQ-V Spring Return Rodless Actuator Package (F-HFCQ32V)
- Model: F-HFCQ32V
- Type: Spring return rodless linear actuator with complete accessory package
- Bore size: Ø32mm
- Stroke range: 50-300mm (in 25mm increments)
- Spring type: Double spring return
- Thrust force: 196N @ 0.6MPa
- Return force: 142N (spring compression force)
- Operating pressure: 0.1-0.8 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Seals: NBR standard (optional FKM/Viton)
- Weight: 2.6kg (with 100mm stroke)
- Dimensions (L×W×H):
- Basic body: 165mm × 45mm × 45mm
- Max extended length: 465mm (300mm stroke)
- Mounting options: Front flange, side flange, or foot mounting
- Protection class: IP65 (standard wiper seal)
- Lubrication: Pre-lubricated (Grease-free operation)
A complete motion solution integrating rodless cylinder and spring return mechanism, designed for space-constrained automation. Features dual anti-rotation guides (precision ±0.5mm) and corrosion-resistant construction. Includes pre-mounted magnetic sensor slots (NPN/PNP compatible) and mounting hardware kit.
- Automatic door locking mechanisms in cleanrooms
- Precision positioning in semiconductor handling robots
- Emergency retract systems for CNC machine guards
- Material clamping in food packaging lines
- Vertical lift assist mechanisms
Installation note:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use supplemental mechanical locks. Lubricate guide shafts every 500km of travel
using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | F-HFCQ32V |
| Bore Diameter | <32 mm> |
