Airtac F-HFCQ-V Spring-Type Push Rod Finished Product Kit F-HFCQ40V
Category: Cylinder Accessories
Brand: AIRTAC
Precision-engineered spring return mechanism with corrosion-resistant plating
Integrated modular design for direct cylinder mounting compatibility
Pre-lubricated components ensuring smooth stroke operation
Standardized interfaces compliant with ISO 6431/6432 pneumatic cylinder specifications
Technical features:
- Double-acting stainless steel return spring
- Hardened guide rod with ±0.01mm concentricity tolerance
- High-cycle PTFE wear-resistant seals
- Ambient temperature range: -10°C to +80°C
AirTAC F-HFCQ-V Spring Return Rod Package F-HFCQ40V Specifications
- Model: F-HFCQ40V (Standard Package)
- Type: Spring-return mechanical pusher with preload adjustment
- Stroke: 40mm ±0.5mm
- Max thrust: 200N (Spring force adjustable via preload collar)
- Repeat positioning accuracy: ±0.2mm
- Spring type: Stainless steel torsion spring (ISO 10243 compliant)
- Operating temperature: -20℃ to +80℃
- Rod material: Chrome-plated steel rod (HRC 58-62)
- Body material: Anodized aluminum alloy (A6063-T5)
- Seal material: High-wear NBR rubber (FDA compliant option available)
- Protection rating: IP54 (Dust protected & water splashed resistance)
- Weight: 1.2kg ±3% (Including mounting hardware)
- Dimensions: 200mm(L) × 32mm(Ø) × 25mm(Mounting hole spacing)
- Mounting options: M6 threaded holes (4x) / 10mm slot for side-mounting
Self-contained linear actuator package combining hardened push rod and precision spring mechanism. Features zero-backlash operation with 3-stage lubrication pockets and anti-rotation keyway. Pre-lubricated with MIL-G-23827 grease for 50,000+ cycles maintenance-free operation. Includes integrated shock absorber to prevent end-position bouncing.
- Carton flap positioning in packaging lines
- PCB board ejection in SMT equipment
- Tooling fixture release mechanisms
- Medical device component alignment
- Conveyor gate actuation systems
Installation guidelines:1. Maintain 0.05mm minimum clearance between rod tip and target surface
2. Align within 0.5° angular deviation using included alignment shims
3. For vertical mounting: Position spring chamber downward to prevent debris accumulation
4. Re-grease every 200,000 cycles using PAG-based lubricant (NLGI #2)
| Property | Property Value |
|---|---|
| sku | F-HFCQ40V |
| Bore Diameter | <40mm> |
