Airtac F-HGS Sensor Mount F-HGS10X10H
$13.92
Regular price
$21.42
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-HGS10X10H
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
F-HGS Sensor Mounting Bracket Complete Assembly (with Magnet)
Category: Magnetic Switch , Brand: AirTAC , Series: F-HGS
Installation protocol:
Apply 0.3-0.5Nm torque during sensor fixation. Use conductive paste
(AS568-012 specification) on mating surfaces for optimal grounding.
Maximum recommended installation speed: 2m/s.
Category: Magnetic Switch , Brand: AirTAC , Series: F-HGS
AirTAC F-HGS10X10H Sensor Mounting Bracket Specifications
- Model: F-HGS10X10H
- Material: Aluminum alloy 6063-T5
- Surface treatment: Black anodized (18-22μm thickness)
- Mounting hole spacing: 10mm × 10mm grid pattern
- Sensor compatibility: M5/M8 threaded inductive/capacitive sensors
- Mounting base thickness: 5mm ±0.1mm
- Thread specifications: M4×0.7 through-holes (4 places)
- Operating temperature: -30℃ to +120℃
- Protection rating: IP67 (with proper sensor sealing)
- Weight: 48g ±2g
- Dimensions: 32mm(L) × 28mm(W) × 18mm(H)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Shock resistance: 100m/s² (3 axes, 11ms duration)
Precision-machined mounting solution for industrial sensors, featuring anti-corrosion coating and EMI shielding properties. The symmetrical design allows 360° rotational adjustment with 15° indexing marks. Includes integrated cable routing channels and stainless steel hardware.
Typical Applications:
- Position detection in CNC machine tooling
- Automated packaging line proximity sensing
- Robotic end-effector alignment systems
- Conveyor belt object detection stations
- Hydraulic cylinder position feedback
Installation protocol:
Apply 0.3-0.5Nm torque during sensor fixation. Use conductive paste
(AS568-012 specification) on mating surfaces for optimal grounding.
Maximum recommended installation speed: 2m/s.
Compatible Accessories:
- F-HGK series mounting brackets (vertical/horizontal extension)
- F-HGP protective shrouds for high particulate environments
- F-HGT thermal insulation kits (>80℃ applications)
