Airtac F-HGS Sensor Mount F-HGS10X20H
Category: Magnetic Switch , Brand: AirTAC , Series: F-HGS
AirTAC F-HGS10X20H Sensor Mounting Bracket Technical Details
- Model Series: F-HGS (Heavy-Gauge Sensor Mount)
- Material: Anodized aluminum alloy 6063-T5
- Mounting Type: Through-hole dual fastening (M4 screws included)
- Sensor Compatibility: Fits Ø10-12mm cylindrical sensors
- Surface Finish: Matte black oxidation (18-22μm coating thickness)
- Weight: 32g ±0.5g
- Dimensions: 20mm(W) × 36mm(H) × 28mm(D)
- Mounting Hole Pattern: 15mm vertical slot with 2×M4 threaded holes
- Temperature Tolerance: -40℃ to +120℃
- Vibration Resistance: 10-55Hz @ 1.5mm amplitude
- IP Rating: IP67 when paired with compatible sensors
Robust sensor mounting solution featuring anti-rotation grooves and dual compression clamps for industrial environments. The thermal-stable design maintains positional accuracy within ±0.1mm across temperature fluctuations. Includes stainless steel M4×16mm hex socket cap screws with vibration-resistant washers.
- CNC machine tool limit switch positioning
- Automated conveyor belt proximity sensor fixation
- Robotic arm end-effector photoelectric sensor mounting
- Food processing equipment (wash-down environment compatible)
- Vibration-heavy applications like stamping presses
Installation protocol:
Apply 0.5-0.8Nm torque during screw tightening. Use thread-locking compound
(Loctite 243 recommended) for permanent installations. Align sensor cable
groove with wiring path before final torque application.
Optional accessories available: Vibration-damping rubber inserts (F-HGS-VIDAMP kit), high-visibility orange anodized version (F-HGS10X20H-OR), and extended temperature range variant (-40℃ to +150℃) with special sealant (F-HGS10X20H-ET).
| Property | Property Value |
|---|---|
| sku | F-HGS10X20H |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
