Airtac F-HGS Sensor Mount F-HGS8X5H
Category: Magnetic Switch , Brand: AirTAC , Series: F-HGS
AirTAC F-HGS8X5H Sensor Mounting Bracket Technical Details
- Model: F-HGS8X5H
- Material: Anodized aluminum alloy (black oxidation)
- Compatible sensor types: M8/M12 inductive/capacitive proximity sensors
- Mounting style: Dual-position adjustable clamp
- Clamp range: 5-8mm diameter sensors
- Thread specifications: M4 mounting holes (x2) with 25mm pitch spacing
- Surface roughness: Ra ≤ 3.2μm
- Operating temperature: -40℃ to +85℃
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Shock resistance: 100m/s² (3 times in XYZ axes)
- Weight: 48g ±2g
- Dimensions: 32mm(L) × 25mm(W) × 18mm(H)
- Protection class: IP67 (when used with compatible sensors)
- Torque specification: 0.4-0.6N·m max tightening torque
Precision-engineered mounting solution for industrial sensors featuring tool-free installation and 360° rotational adjustment. The hardened aluminum construction withstands mechanical stress while maintaining dimensional stability. Integrated cable management slots (3mm width) enable clean routing.
- Position verification in CNC machine tooling systems
- Object detection on high-speed packaging conveyors
- Pallet presence sensing in AS/RS warehouses
- Safety interlock systems for robotic workcells
- Liquid level monitoring in food processing equipment
Installation protocol:
Apply anti-vibration thread locker (medium strength) to mounting screws.
Ensure sensor body clearance from metal surfaces ≥3mm to prevent
interference with detection fields. Perform alignment verification
using laser measurement tools for critical positioning applications.
| Property | Property Value |
|---|---|
| sku | F-HGS8X5H |
| Bore Diameter | <8mm> |
| Stroke | <5mm> |
