Airtac F-JSI-CA Single Ear Bracket Assembly Kit F-JSI125CA
AirTAC F-JSI-CA Single-Ear Mounting Bracket Kit F-JSI125CA Technical Details
- Model: F-JSI125CA (Complete Kit)
- Type: Single-flange cylinder mounting bracket
- Material: Aluminum alloy ADC12
- Surface treatment: Anodized (natural aluminum color)
- Mounting hole diameter: Ø12.5mm
- Compatible cylinder bore: 125mm series
- Max load capacity: 1,800N (static)/1,200N (dynamic)
- Fastener torque: 45-50N·m (M12 bolts)
- Temperature range: -20℃ to 80℃
- Corrosion resistance: 500hr salt spray test passed
- Weight: 2.35kg ±2%
- Dimensions: 178mm(L) × 145mm(W) × 62mm(H)
Heavy-duty single-ear bracket kit with precision CNC machining, designed for secure mounting of 125mm bore pneumatic cylinders. Features vibration-damping design with 2mm thick rubber padding (Shore A 70±5) at contact surfaces. Includes all necessary Grade 12.9 mounting hardware and anti-loosening washers.
- Vertical cylinder mounting in automated assembly lines
- Robotic arm joint fixation
- Packaging machinery linear actuator support
- Press tooling equipment installations
- Material handling system pivot points
Installation protocol:
Use torque wrench for bolt tightening and maintain parallel alignment within 0.2mm/m.
Apply thread-locking compound (LOCTITE 243 recommended) for high-vibration environments.
Clean mounting surfaces with isopropyl alcohol before assembly.
| Property | Property Value |
|---|---|
| sku | F-JSI125CA |
