Airtac F-JSI-CA Single Ear Bracket Assembly Kit F-JSI80CA
$18.57
Regular price
$26.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-JSI80CA
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Cylinder Accessories
Brand: AIRTAC (Aidem)
Series: F-JSI-CA Single Ear Bracket Kit
Technical Specification:
Precision-engineered single ear mounting bracket assembly designed for pneumatic cylinder stabilization. Compatible with ISO 6431/ISO 15552 standard cylinders. Features high-grade aluminum alloy construction with anodized surface treatment for corrosion resistance and extended service life. Enables secure mounting and axial alignment to minimize lateral loads on cylinder rods. Includes pre-assembled hardware kits (bolts/nuts) for rapid field installation. Certified for industrial automation systems requiring vibration-damped mounting solutions.
Key Attributes:
• Integrated anti-rotation design
• ±0.1mm positional tolerance machining
• Dual-bearing support configuration
• ADK-SMC series cross-compatibility
• IP54 environmental protection rating
Installation protocol:
Use calibrated torque wrench for bolt tightening. Apply 0.5mm shim between bracket and cylinder
when mounting on uneven surfaces. Perform re-torque check after 50 operating cycles.
Compatibility note:
Not suitable for rotary actuators or applications exceeding 15Hz vibration frequency.
Use stainless steel variant (F-JSI80CA-SS) in chemical environments.
AirTAC F-JSI-CA Single Ear Bracket Kit F-JSI80CA Technical Details
- Model: F-JSI80CA (Complete Bracket Kit)
- Type: Single ear fixed mounting bracket
- Material: Aluminum alloy ADC12
- Compatible cylinder series: MY1B/MY2B/MY3B standard series
- Bore size compatibility: Ø80mm cylinders
- Mounting hole diameter: Ø12.5mm (precision reamed)
- Fastener specs: M8×1.25 mounting bolt included
- Torque specification: 14-18N·m (using Class 8.8 bolt)
- Surface treatment: Matte black anodizing (Alodine 1200S)
- Corrosion resistance: 48hr salt spray test passed
- Temperature resistance: -20℃ to 80℃
- Weight: 348g ±5g (including all hardware)
- Dimensions: 80mm(L) × 40mm(W) × 30mm(H)
- Package contents: Bracket body, M8×25 hex bolt, flat/spring washers, installation manual
Heavy-duty single ear mounting solution for precise cylinder alignment in high-moment applications. Features CNC-machined locating surfaces (Ra3.2 finish) and anti-vibration tooth design on mating surfaces. Includes pre-applied thread locker on fasteners for industrial environments.
Common Implementations:
- Pneumatic press brake tooling setups
- Assembly line clamping mechanisms
- Material handling robot EOAT mounting
- Plastic injection molding ejector systems
- Vertical actuator installations requiring cantilever support
Installation protocol:
Use calibrated torque wrench for bolt tightening. Apply 0.5mm shim between bracket and cylinder
when mounting on uneven surfaces. Perform re-torque check after 50 operating cycles.
Compatibility note:
Not suitable for rotary actuators or applications exceeding 15Hz vibration frequency.
Use stainless steel variant (F-JSI80CA-SS) in chemical environments.
