Airtac F-JSI-CR Single Angled Lug Bracket Assembly Kit F-JSI125CR
AirTAC F-JSI-CR Single Cantilever Bracket Kit F-JSI125CR Technical Details
- Model: F-JSI125CR (Complete Bracket Kit)
- Type: Single offset mounting bracket with pre-assembled hardware
- Material: Aluminum alloy ADC12
- Surface treatment: Black anodized (Alodine 1200S equivalent)
- Mounting hole size: M5×0.8 threaded (2 holes)
- Load capacity: 30kg dynamic / 60kg static
- Compatible rail width: 125mm ±0.5mm (Standard SHS/SLF series)
- Temperature resistance: -20℃ to +80℃
- Anti-corrosion rating: 96hrs salt spray test passed
- Weight: 0.45kg ±3% (including fasteners)
- Dimensions: 150mm(L) × 50mm(W) × 25mm(H)
- Hardware included: M5×12mm stainless steel screws (2pcs), spring washers (2pcs)
- Vibration resistance: 5-2000Hz, 15m/s² max
- IP rating: IP54 (when installed with compatible components)
Heavy-duty cantilever bracket engineered for precision alignment in linear motion systems. Features 15° offset design allowing component clearance in confined spaces. The CNC-machined base ensures ±0.1mm positional repeatability during reinstallation. Includes anti-vibration washers to prevent loosening under continuous operation.
- Linear guide end-stop mounting for CNC routers
- Sensor/encoder fixation on automated assembly lines
- Pneumatic cylinder stabilization in packaging machinery
- Conveyor system auxiliary component support
- Robotic arm tooling plate reinforcement
Installation protocol:
Apply 2.5-3.0N·m torque during screw tightening. Use thread locker (LOCTITE 243 recommended)
for high-vibration environments. Compatible with M5 helicoil inserts for soft material mounting.
F-JSI-EX125 (Extension plate for dual bracket configurations)
AJS-M6K (M5-M6 thread adapter kit)
Surface preparation kit (SC-02 cleaning solvent & adhesion promoter)
| Property | Property Value |
|---|---|
| sku | F-JSI125CR |
