Airtac F-JSI-LB Axial Mounting Bracket Assembly Kit F-JSI63LB
AirTAC F-JSI-LB Axial Fixing Bracket Kit F-JSI63LB Technical Details
- Model: F-JSI63LB (Complete Unit Package)
- Type: Pre-assembled axial fixing bracket set
- Material: Aluminum alloy ADC12
- Compatible rail series: SHS15/SHS20/SHS25/SHS30/SHS35
- Mounting hole spacing: 50±0.1mm standard pattern
- Installation hole size: M6 threaded (4 holes)
- Clamping torque: 2.5-3.0 N·m (recommended)
- Surface treatment: Black anodized oxidation
- Operating temperature: -20℃ to 80℃
- Protection rating: IP54 (dust protected & water splashed)
- Weight: 0.65 kg ±5%
- Dimensions: 63mm(L) × 20mm(W) × 30mm(H)
- Included accessories: 4×M6×12 hex socket screws, 4×spring washers
Precision-machined fixing solution for linear guide systems, featuring pre-drilled alignment holes and anti-corrosion coating. The integrated design eliminates secondary processing, with hardened contact surfaces (HRC 45±2) ensuring wear resistance. Includes vibration-damping washers for high-speed applications.
- Linear motion module end-stop fixation
- CNC machine tool carriage positioning
- Semiconductor wafer handling robots
- Automated packaging line sliding units
- 3D printer gantry axis stabilization
