Airtac F-M-F Floating Joint Assembly F-M10X125F
AirTAC F-M-F Floating Joint Assembly F-M10X125F Technical Details
- Full Model Code: F-M10X125F
- Type: Pre-assembled floating joint kit with female thread
- Thread Specification: M10×1.5 (ISO metric fine thread)
- Stroke Length: ±1.25mm radial compensation
- Max Angular Misalignment: ±2°
- Material Composition:
- Main Body: Anodized aluminum alloy 6061-T6
- Ball Joint: Hardened stainless steel SUS304
- Seals: High-wear NBR rubber (70±5 Shore A)
- Working Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃ (continuous use)
- Torque Capacity: 3.5 N·m max
- Mounting Orientation: Omnidirectional (horizontal/vertical)
- Weight: 298g ±5g (complete assembly)
- Dimensions:
- Total Length: 125mm (thread engagement excluded)
- Flange Diameter: 24mm
- Hex Size: 17mm wrench flat
- Rod End Clearance: 8mm radial space required
Precision-machined floating joint designed to compensate for axial/radial misalignment in pneumatic and low-torque mechanical linkages. Features dual-stage sealing with integrated dust wiper, rated for 500,000+ cycles at 0.5MPa. Includes pre-installed thread locker and alignment spacers.
- Pneumatic cylinder rod-end connections in pick-and-place robots
- Vibration damping in CNC tool changer mechanisms
- Misalignment compensation for conveyor belt tracking systems
- Shock absorption in packaging machine sealing heads
- Precision alignment in semiconductor wafer handling arms
Maintenance Advisory:
Apply lithium-based grease (NLGI #2) every 2,000 operating hours.
Avoid side impact loads exceeding 150N. For vacuum applications,
use optional fluorocarbon seals (FKM version available).
| Property | Property Value |
|---|---|
| sku | F-M10X125F |
| Thread Pitch | 1.25mm |
| Thread Specification | <10mm> |
