Airtac F-M-F Floating Joint Assembly F-M14X150F
$18.57
Regular price
$26.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-M14X150F
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Floating Joint Assemblies
Brand: AirTAC
Series: F-M-F Flange-Type Rod End Couplings
Professional Description:
AirTAC F-M-F Series Floating Joints are precision-engineered misalignment compensators designed for pneumatic and automation systems. This complete assembly features dual-flange connectivity with male/female threaded interfaces (F-M-F configuration), enabling angular deflection compensation up to ±5° and parallel offset absorption. Constructed with hardened steel swivel joints and corrosion-resistant mounting hardware, these industrial-grade couplings ensure reliable torque transmission while mitigating lateral stresses in cylinder-rod and mechanical linkage applications. The pre-lubricated bearing surfaces provide smooth articulation for high-cycle operations, making them ideal for robotic end-effector connections and precision alignment-critical installations.
Installation guidelines:
Apply thread sealant (PTFE tape or liquid) to male threads before assembly.
Tighten to 14-16 N·m torque using a crowfoot wrench. Avoid side-loading during
operation - ensure minimum 5mm clearance around moving parts.
AirTAC F-M-F Floating Joint Assembly F-M14X150F Technical Specifications
- Model: F-M14X150F
- Type: Standard floating joint with male thread ends
- Thread specification: M14×1.5 (both ends)
- Total length: 150mm ±0.5mm
- Float range: ±2mm radial displacement
- Angular compensation: ±3°
- Material: Anodized aluminum alloy body, steel retaining rings
- Seal type: NBR rubber O-rings
- Working pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃ (NBR compatible)
- Weight: 220g ±5g
- Dimensions: 150mm(L) × 22mm(Ø) × 38mm(H flange)
- Surface treatment: Hard anodized (25μm thickness)
- Rotation capability: 360° continuous rotation
- Max lateral load: 50N
Precision-engineered floating joint assembly designed to compensate for axial misalignment in pneumatic systems. Features double O-ring seals and hardened contact surfaces for reduced wear. The chrome-plated steel pins ensure smooth articulation under load.
Typical Applications:
- Pneumatic cylinder rod-end connections
- Automated material handling systems
- Packaging machinery alignment compensation
- Robotic end-effector mounting interfaces
- Conveyor system shock absorption
Installation guidelines:
Apply thread sealant (PTFE tape or liquid) to male threads before assembly.
Tighten to 14-16 N·m torque using a crowfoot wrench. Avoid side-loading during
operation - ensure minimum 5mm clearance around moving parts.
Service life:
Recommended replacement after 500,000 cycles or if axial play exceeds 0.8mm.
Lubricate monthly with ISO VG32 hydraulic oil for high-cycle applications.
| Property | Property Value |
|---|---|
| sku | F-M14X150F |
| Thread Pitch | 1.5mm |
| Thread Specification | 14mm |
