Airtac F-M-F Floating Joint Assembly F-M22X150F
AirTAC F-M-F Floating Joint Assembly F-M22X150F Technical Details
- Full model designation: F-M22X150F
- Series: F-M-F precision floating joint series
- Thread specification: M22×1.5 male-female thread
- Effective stroke: ±2.5mm (axial compensation)
- Angular compensation: ±3° (max deviation)
- Max working pressure: 0.7 MPa
- Pressure rating: 1.0 MPa burst pressure
- Body material: Anodized aluminum alloy (A6063-T5)
- Ball seat material: Polished stainless steel (SUS304)
- Spring material: Chrome silicon alloy steel
- Operating temperature: -20℃ to +80℃
- Surface hardness: HV 400-450 (bearing surfaces)
- Weight: 228±5g (complete assembly)
- Dimensions: 150mm(L) × 32mm(Ø body) × 42mm(Ø flange)
- Thread engagement depth: 12mm (male), 10mm (female)
- Rotation capability: 360° continuous rotation
- Vibration resistance: 5-2000 Hz frequency range
- ISO standard: Compliant with ISO 13094-2013
High-precision floating joint with triple compensation (axial, angular, and parallel offset) for pneumatic systems requiring misalignment correction. Features hard-anodized wear surfaces and maintenance-free operation. The chromium-plated spring provides consistent tension force of 12-15N throughout the stroke. Includes integrated dust wiper (PU material) for contamination protection.
- Industrial robot end-effector tool changers
- High-speed pick-and-place pneumatic actuators
- CNC machine tool automatic tool clamping systems
- Packaging line rotary joint compensation
- Semiconductor wafer handling vacuum arms
Mounting protocol:
Apply 2-3 drops of ISO VG32 pneumatic oil to ball interface during assembly.
Torque limit: 25-30 N·m for M22 thread. Always install lock nut (included)
with 120° offset from joint orientation. Verify free movement post-installation
through full ±2.5mm travel.
- Optimal pairing with AirTAC MAL20/MAL25 linear guides
- Compatible with SMC MGPM/MK2 series cylinders
- Requires 16mm ID polyurethane tubing (max 12 bar)
| Property | Property Value |
|---|---|
| sku | F-M22X150F |
| Thread Pitch | 1.5mm |
| Thread Specification | 22mm |
