Airtac F-M-F Floating Joint Assembly F-M27X200F
AirTAC F-M-F Series Floating Joint Assembly F-M27X200F Technical Details
- Full model designation: F-M27X200F
- Joint type: Double-ended floating connector with axial compensation
- Thread specification: M27×2.0 (metric fine thread)
- Effective stroke: ±2.5° angular misalignment / ±1.5mm parallel offset
- Max load capacity: 1,200N (static), 800N (dynamic)
- Body material: Anodized aluminum alloy AL6061-T6
- Bearing type: Precision ball bearing with PTFE-coated raceway
- Seal material: HNBR rubber (temperature-resistant variant)
- Operating temperature: -30℃ to +120℃
- Surface hardness: HV 400-450 (anodized layer)
- Anti-rotation mechanism: Hexagonal flange with 46mm AF
- Weight: 580g ±2% (including all hardware)
- Dimensions: 200mm(L) × 46mm(W) × 46mm(H)
- Mounting torque: 85-95N·m (thread engagement)
- Vibration resistance: 10-2000Hz, 15G acceleration
High-precision floating joint designed for heavy-duty motion systems requiring compensation of mechanical misalignment. Features triple-sealed bearing chambers and military-grade surface treatment, providing exceptional corrosion resistance in humid environments. The through-hardened pivot pins (HRC 58-62) ensure extended service life in high-cycle applications.
- Robotic welding arm position compensation
- CNC machine tool automatic tool changers
- Packaging line rotary index table linkages
- Semiconductor wafer handling robots
- Hydraulic cylinder pilot connection systems
Installation protocol:
Apply medium-strength thread locker (LOCTITE 243 recommended) on male threads.
Perform alignment calibration using dial indicator (max 0.1mm TIR tolerance).
Torque sequence: pre-tighten to 30% spec value, then cross-tighten in three stages.
| Property | Property Value |
|---|---|
| sku | F-M27X200F |
| Thread Pitch | <2.0mm> |
| Thread Specification | 27mm |
