Airtac F-M-Y Connector Assembly Kit F-M12X125Y
$11.59
Regular price
$19.09
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-M12X125Y
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Name: Y-Type Pneumatic Cylinder Fitting Assembly Kit
Brand: AIRTC (Airtac International Group)
Series: F-M-Y
Description:
This F-M-Y series Y-connector assembly is engineered for precision pneumatic circuit connections in industrial automation systems. Featuring a corrosion-resistant brass construction with triple-port configuration (1 female / 2 male threaded ends), the compact fitting ensures secure branch line connections for pneumatic cylinders and actuator controls. Pre-assembled with OEM-grade sealing components and protective nylon sleeves, the kit delivers leak-proof performance under working pressures up to 1.0 MPa. Compliant with ISO 16030 pneumatic connection standards, it supports 6mm/8mm OD tubing for optimized airflow distribution in multi-cylinder arrangements.
Installation protocol:
Apply thread sealant only on male threads (not required for pre-sealed units).
Use two wrenches spaced 90° apart for torque distribution.
Maximum 3 reuses recommended for optimal sealing performance.
AirTAC F-M-Y Fitting Assembly F-M12X125Y Technical Specifications
- Full model designation: F-M12X125Y (Complete assembly kit)
- Thread specification: M12×1.5 male thread
- Effective length: 125±0.5mm
- Body material: Nickel-plated brass CW617N
- Seal material: HNBR (Hydrogenated Nitrile) O-rings
- Pressure rating: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to +80℃ (continuous operation)
- Surface treatment: Electro-less nickel plating (5-8μm)
- Torque specification: 12-15 N·m installation torque
- Weight: 118g ±2% (including packaging)
- Dimensions: 125mm(L) × 16mm(Ø) × 16mm(Ø) (cylindrical body)
- Flow coefficient: Cv 0.32
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Protection class: IP67 (when properly installed)
Pre-assembled pneumatic fitting kit with integrated flow control, designed for precision gas/liquid line connections in confined spaces. Features anti-vibration thread locking and chemical-resistant seals. Includes pre-installed backup washer and torque-limiting flange.
Industrial Applications:
- Robotic arm pneumatic gripper connections
- CNC machine tool coolant line interfaces
- Semiconductor manufacturing gas delivery systems
- Electric vehicle battery cooling manifolds
- Pharmaceutical liquid transfer systems
Installation protocol:
Apply thread sealant only on male threads (not required for pre-sealed units).
Use two wrenches spaced 90° apart for torque distribution.
Maximum 3 reuses recommended for optimal sealing performance.
| Property | Property Value |
|---|---|
| sku | F-M12X125Y |
| Thread Pitch | 1.25mm |
| Thread Specification | 12mm |
