Airtac F-M-Y Connector Assembly Kit F-M14X150Y
AirTAC F-M-Y Fitting Assembly Kit F-M14X150Y Technical Details
- Full model designation: F-M14X150Y
- Product type: Metric male-threaded pneumatic fitting assembly
- Thread specification: M14×1.5 external thread (ISO 6149 standard)
- Material composition:
- Body: 304 stainless steel (electropolished finish)
- Seat: PTFE-reinforced PPS composite
- Locknut: Zinc-nickel plated carbon steel
- Effective length: 150mm ±0.5mm (thread tip to hex base)
- Weight: 285g ±5g (including all assembly components)
- Critical dimensions:
- Total assembled length: 162mm
- Hex size: 22mm across flats
- Thread engagement length: 12mm
- Tube OD compatibility: 8mm (1/4") to 12mm (15/32")
- Temperature tolerance: -40℃ to 150℃ (continuous operation)
- Sealing elements: HNBR O-rings (high nitrile content)
- Pressure rating:
- Max working pressure: 1.5MPa (217psi)
- Burst pressure: ≥4.5MPa
- Certifications: CE 2014/68/EU, RoHS 2011/65/EU
Heavy-duty transition fitting designed for high-vibration environments, featuring triple-seal technology with redundant sealing surfaces. The precision-machined M14×1.5 thread profile ensures leak-free connections in hydraulic and pneumatic systems. Anti-rotation flats prevent tool slippage during installation.
- Bridge connections between ISO 1179 ports and JIS B8381 manifolds
- Retrofitting legacy equipment with modern pneumatic components
- High-cycle automation cells in automotive welding systems
- Coolant line adapters for CNC machining centers
- Vacuum system interfaces in semiconductor manufacturing
Installation protocol:
Apply 2.5-3Nm torque during final tightening. Use anaerobic thread sealant (LOCTITE 577 recommended) for gas applications. Perform pressure test at 1.1× system pressure after installation.
| Property | Property Value |
|---|---|
| sku | F-M14X150Y |
| Thread Pitch | 1.5mm |
| Thread Specification | 14mm |
