Product Name: Y-Type Pneumatic Cylinder Fitting Assembly Kit
Brand: AIRTC (Airtac International Group)
Series: F-M-Y
Description:
This F-M-Y series Y-connector assembly is engineered for precision pneumatic circuit connections in industrial automation systems. Featuring a corrosion-resistant brass construction with triple-port configuration (1 female / 2 male threaded ends), the compact fitting ensures secure branch line connections for pneumatic cylinders and actuator controls. Pre-assembled with OEM-grade sealing components and protective nylon sleeves, the kit delivers leak-proof performance under working pressures up to 1.0 MPa. Compliant with ISO 16030 pneumatic connection standards, it supports 6mm/8mm OD tubing for optimized airflow distribution in multi-cylinder arrangements.
Installation Tip:
For optimal sealing, insert tubing until hearing a distinct "click" and perform
a pull-out force test (minimum 15N required). Lubricate threads with PTFE grease
when used in high-cycle applications (>50,000 connections).
Compatibility Note:
Not suitable for hydraulic fluids or aggressive chemicals. Maximum
intermittent temperature peaks must not exceed 100℃.
AirTAC F-M-Y Quick Coupling Kit F-M3X050Y Technical Specifications
- Full Model Number: F-M3X050Y
- Series: F-M-Y Compact Push-to-Connect
- Thread Specification: M3×0.5 (Metric Fine)
- Body Material: Brass with Nickel Plating
- Seal Material: NBR (Nitrile Rubber)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to +80℃
- Tube Compatibility: Ø4mm OD Pneumatic Tubing
- Package Contents: 5 pcs/pack (Male/Female complete assemblies)
- Thread Engagement Depth: 3.5±0.3mm
- Leakage Rate: ≤0.1 NL/min @ 0.5MPa
- Weight: 18g per assembly (total 90g/pack)
- Dimensions per Unit: 22mm(L) × 10mm(W) × 8mm(H)
- Vibration Resistance: 10-55Hz @ 1.5mm amplitude
- Certifications: RoHS compliant
Pre-assembled quick-disconnect fittings with precision-machined threads and positive-lock mechanism. Features 180° swivel capability for hose alignment and anti-spill valve design. The nickel-plated brass construction ensures corrosion resistance in humid environments.
Ideal for:
- Modular pneumatic circuit assembly in robotics
- Sensor air supply connections in semiconductor equipment
- Portable medical devices requiring quick hose changes
- Food-grade CO₂ delivery systems (when using compatible seals)
- 3D printer pneumatic extruder connections
Installation Tip:
For optimal sealing, insert tubing until hearing a distinct "click" and perform
a pull-out force test (minimum 15N required). Lubricate threads with PTFE grease
when used in high-cycle applications (>50,000 connections).
Compatibility Note:
Not suitable for hydraulic fluids or aggressive chemicals. Maximum
intermittent temperature peaks must not exceed 100℃.
| Property | Property Value |
|---|---|
| sku | F-M3X050Y |
| Thread Pitch | <0.5 mm> |
| Thread Specification | <3mm> |
