Airtac F-M-Y Connector Assembly Kit F-M8X125Y
AirTAC F-M-Y Series Fitting Kit F-M8X125Y Technical Details
- Full model designation: F-M8X125Y
- Series: F-M-Y Compact Pneumatic Fittings
- Thread specification: M8×1.0 male thread (ISO 261 metric)
- Effective length: 125mm ±0.5mm tolerance
- Body material: CNC-machined 6063-T5 aluminum alloy
- Surface treatment: Anodized finish (natural silver)
- Seal components: HNBR (Hydrogenated Nitrile) O-rings
- Temperature resistance: -20°C to +120°C continuous operation
- Pressure rating: 0.05-1.0 MPa (7-145 PSI)
- Tube compatibility: 6mm OD polyurethane/nylon tubing
- Insertion force: ≤25N (with factory lubrication)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Weight: 48g ±2g (including packaging)
- Dimensions: 145mm(L) × 18mm(W) × 12mm(H)
- Package contents: 10 pcs/box with anti-corrosion paper wrap
Precision-engineered push-to-connect fittings with integrated flow control, featuring dual-stage sealing technology for leak-free performance in dynamic pneumatic systems. The knurled grip surface ensures tool-free installation while maintaining 360° rotatability post-installation. Nickel-plated brass inserts prevent galvanic corrosion with aluminum components.
- Robotic arm pneumatic circuits (ISO 9409-1 flange compatible)
- Food processing equipment (FDA-compliant seal options available)
- Semiconductor manufacturing gas lines (high-purity variant F-M8X125Y-P)
- Mobile hydraulic test bench connections
- CNC machine tool coolant line conversions
Installation protocol:
Cut tubing ends square (max 0.5° angular error) and deburr before insertion.
For maintenance cycles, replace O-rings every 50,000 actuations or 2 years
(whichever comes first) using service kit F-M-Y-SK8.
| Property | Property Value |
|---|---|
| sku | F-M8X125Y |
| Thread Pitch | 1.25mm |
| Thread Specification | <8mm> |
