Airtac F-MA-FA Front Flange Mounting Plate Kit F-MA16FA
AirTAC F-MA-FA Front Flange Mounting Plate Kit F-MA16FA Technical Details
- Model: F-MA16FA (Complete assembly kit)
- Material: Anodized aluminum alloy 6063-T5
- Mounting pattern: ISO 15552 (formerly ISO 6432) compatible
- Bore size compatibility: ø16mm cylinders
- Mounting hole spacing: 30mm±0.1mm (horizontal) × 40mm±0.1mm (vertical)
- Thread specifications: M5×0.8 mounting screws (4 places)
- Surface hardness: HV 80-100
- Surface treatment: Clear anodized (8-12μm thickness)
- Fastener material: Stainless steel screws (SUS304)
- Anti-vibration design: Integrated rubber dampeners (Shore A 70±5)
- Weight: 228g ±5g (complete kit with hardware)
- Dimensions: 62mm(L) × 48mm(W) × 12mm(H)
- Temperature range: -20℃ to 120℃ (continuous operation)
- Corrosion resistance: 96hr salt spray test passed
Precision-engineered mounting solution for cylinder fixation, featuring anti-loosening thread locker pre-applied on fasteners. The diamond-knurled surface enhances grip during installation while maintaining alignment accuracy within ±0.05mm. Compatible with pneumatic systems requiring IP54 environmental protection.
- Robotic arm joint articulation systems
- Vertical lift mechanisms in packaging lines
- Semiconductor wafer handling equipment
- Medical bed adjustment actuators
- Food processing conveyor belt tensioners
Installation protocol:
Apply 2.5-3.0Nm torque using calibrated torque wrench during assembly.
For vertical installations, use supplementary thread-locking adhesive on
load-bearing fasteners. Avoid galvanic corrosion by isolating from
dissimilar metals in humid environments.
| Property | Property Value |
|---|---|
| sku | F-MA16FA |
