Airtac F-MA-Y Adapter Assembly Kit F-MA20Y
AirTAC F-MA-Y Series Quick-Connect Fitting Assembly - F-MA20Y Technical Details
- Model Code: F-MA20Y (Complete Assembly Kit)
- Thread Specification: M5 × 0.8 Male Thread Ends
- Material Body: Nickel-plated Brass (ISO 1179 Standard)
- Seal Components: HNBR O-Rings (-20℃ to 150℃ rated)
- Max Working Pressure: 1.5 MPa (217.5 PSI)
- Burst Pressure: ≥4.5 MPa
- Flow Rate (Qn): 120 NL/min @ 0.5 MPa
- Weight: 28g ±1g (Per Assembly Unit)
- Dimensions: 32mm(Overall L) × 16mm(W) × 12mm(H)
- Vibration Resistance: 10-2000Hz, 15G Acceleration
- IP Rating: IP40 (Non-weatherproof indoor use)
- Compliance: RoHS 2011/65/EU Directive
Pre-assembled pneumatic quick-disconnect solution with precision-machined tapered threads for zero-leak performance. Features anti-vibration locking sleeve design with 3° push-to-connect angle optimization. Compatible with PU, nylon, and rubber tubing (ID 2.5-3.2mm). Includes factory-tested leak detection certification.
- Modular pneumatic circuit connections in CNC tool changers
- Quick-release tooling interfaces for robotic EOAT systems
- Compressed air distribution in semiconductor wafer handlers
- Maintenance bypass ports for injection molding machines
- Modular pneumatic test bench configurations
Installation Protocol:
Apply 0.8-1.2 N·m torque during installation. Perform initial purge with
dry air (dew point ≤3℃) before pressure testing. Replace O-rings every
50,000 cycles in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | F-MA20Y |
