Airtac F-MF-LB Axial Fixing Frame Assembly Kit F-MF40LB
AirTAC F-MF-LB Axial Fixation Bracket Kit F-MF40LB Technical Details
- Model: F-MF40LB (Complete Bracket Assembly Kit)
- Type: Precision Linear Shaft Support Unit
- Material: Aluminum Alloy 6063-T5 (Hard Anodized)
- Axial Load Capacity: 850N Static / 350N Dynamic
- Mounting Hole Pattern: 32mm × 32mm Square (M6 Thread)
- Shaft Compatibility: Ø8-40mm Diameter
- Surface Hardness: HV 400±20
- Temperature Range: -30℃ to 120℃
- Corrosion Resistance: 500hr Salt Spray Test Pass
- Weight: 620g ±5% (Including Fasteners)
- Dimensions: 78mm(L) × 52mm(W) × 45mm(H)
- Surface Finish: Micro-arc Oxidation Coating (10-15μm)
- Tolerance Grade: ISO h7 Shaft Fit
- Included Components: Bracket Body, Locking Collars (2), Set Screws (4), Shim Washers
Heavy-duty linear motion support system featuring dual angular contact bearings for smooth axial movement under high moment loads. Precision-machined with laser-etched alignment marks for simplified installation. Includes anti-vibration nylon-tipped set screws and corrosion-resistant hardware.
- CNC Z-axis lead screw stabilization
- Automated packaging line conveyor guides
- 3D printer gantry support structures
- Medical imaging equipment sliding mechanisms
- Solar panel tracking system pivot points
Installation protocol:
Apply MOBILITH SHC 100 grease to bearing surfaces before assembly.
Torque M6 fasteners to 8-10Nm using crisscross pattern.
Verify shaft runout ≤0.02mm after installation.
