Airtac F-MF-SDB Rear Hinge Bracket Assembly Kit F-MF32SDB
AirTAC F-MF-SDB Rear Hinge Bracket Kit F-MF32SDB Technical Details
- Model: F-MF32SDB (Complete Bracket Assembly)
- Material: Anodized Aluminum Alloy 6063-T5
- Surface Treatment: Black Oxidation (MIL-A-8625 Type III)
- Mounting Hole Pattern: Dual 8.5mm slots with M6 thread inserts
- Compatible Cylinder Series: MF-32/40/50/63 standard bore cylinders
- Angular Adjustment Range: ±5° vertical plane adjustment
- Static Load Capacity: 220N (axial), 150N (radial)
- Operating Temperature: -20℃ to +120℃ (continuous)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Weight: 485g ±10g (including all mounting hardware)
- Dimensions: 78mm(L) × 42mm(W) × 34mm(H) (excluding protrusions)
- Hardware Included: 4×M6×16mm stainless steel bolts, 8×spring washers
Precision-machined pivot bracket system designed for precision alignment compensation in multi-axis pneumatic systems. Features dual-stage friction locking with 12Nm torque-rated clamping force, enabling micro-adjustments while maintaining positional stability under dynamic loads. Includes anti-vibration shim plates for dampening high-frequency oscillations.
- Multi-station rotary index table synchronization
- Robotic end-effector mounting with thermal expansion compensation
- Vibration-sensitive metrology equipment support structures
- Modular production line quick-change tooling interfaces
- Packaging machine cam follower stabilization systems
Installation Protocol:
Apply 2-3Nm pre-torque during initial alignment, then final tighten to 8Nm using
cross-pattern sequence. Lubricate pivot points with ISO VG32 hydraulic oil
before operation. Avoid overtightening beyond 12Nm to prevent bushing deformation.
| Property | Property Value |
|---|---|
| sku | F-MF32SDB |
