Airtac F-MF-TC End Cover Trunnion Bracket Assembly Kit F-MF32TC
AirTAC F-MF-TC Trunnion Mount Bracket Kit (F-MF32TC) Specifications
- Model: F-MF32TC
- Type: End Cover Trunnion Mount Bracket Kit
- Material: Aluminum alloy ADC12
- Surface treatment: Anodized (natural silver)
- Bore size compatibility: Φ32mm cylinders
- Mounting type: Dual trunnion pivot with locking nuts
- Rotation range: ±5° axial adjustment
- Max load capacity: 180N radial / 250N axial
- Mounting hole spacing: 40±0.2mm (center-to-center)
- Thread specifications: M8×1.25 mounting threads
- Operating temperature: -20℃ to 80℃
- Protection level: IP54 (standard configuration)
- Weight: 0.25kg ±5%
- Dimensions: 78mm(L) × 42mm(W) × 35mm(H)
Precision-engineered mounting solution for cylinder stabilization, featuring dual-axis alignment capability with corrosion-resistant anodized finish. Includes pre-assembled mounting hardware (M8 hex nuts and washers) for direct installation. Designed to absorb vibration and prevent lateral drift in dynamic applications.
- Rotary clamp positioning in automated assembly lines
- Pneumatic actuator support for material handling robots
- Angular adjustment in packaging machine pusher mechanisms
- Vibration dampening for CNC tool changers
- Medical equipment actuator mounting with sterile environment compliance
Installation protocol:
Apply 20-25N·m torque during M8 screw tightening. Use thread-locking compound
in high-vibration environments. Perform alignment verification using 0.02mm
feeler gauge between bracket and cylinder body.
| Property | Property Value |
|---|---|
| sku | F-MF32TC |
