Product Name: Pneumatic Cylinder Y-Type Fitting Assembly
Brand: AirTAC
Series: F-MF-Y
Specification Highlights:
- Material: Brass with Nickel Plating (Corrosion-Resistant Finish)
- Connection Type: Y-Branch Compact Design for Space-Constrained Installations
- Thread Standards: Metric/PT/NPT Thread Options Available (ISO 1179 Compliance)
- Pressure Rating: 0-1.0 MPa Operating Range
- Temperature Range: -5°C to 60°C (23°F to 140°F)
- Leakage Class: ≤0.1 NL/min (Class 4 per ISO 6952)
- Applications: Multi-circuit air distribution in pneumatic systems, compatible with PU/Nylon tubing
Package Configuration:
Pre-assembled kit includes:
1× Y-Type Fitting Body (Brass)
3× Sealing Elements (NBR O-Rings)
3× Thread Protectors
Installation Guide (EN/CN Bilingual)
Key Features:
① Precision CNC-machined thread interfaces ensuring bubble-tight seal
② 360° rotatable branch ports for flexible piping alignment
③ Compact footprint reduces system weight by 25% vs conventional fittings
④ Passed 1 million cycle endurance test (ISO 19973-1 certified)
Industry Compliance:
• RoHS 2011/65/EU compliant
• REACH SVHC < 0.1%
• Pneumatic Fitting Directive 2014/68/EU
Typical Use Cases:
- Modular pneumatic circuit branching in automation equipment
- Air preparation unit piping networks
- Robotic EOAT (End-of-Arm Tooling) pneumatic distribution
Note: For optimal performance with AirTAC SDA/SME series cylinders, recommend using with AS1200 series tube sleeves.
Installation protocol:
Cut tubing ends square and deburr before insertion. For optimal seal life,
perform 2-3 full connection cycles before final installation. Maximum
allowable angular misalignment: 3°.
Compatibility note:
Not suitable for glycol-containing fluids or phosphate ester-based
lubricants. Flush system with dry air after each disconnection cycle.
AirTAC F-MF-Y Series F-MF20Y Quick Connector Kit Specifications
- Model: F-MF20Y (Complete Assembly Kit)
- Type: Push-to-connect straight thread joint
- Body Material: Nickel-plated brass (C3604)
- Seal Material: NBR/POM composite
- Thread Standard: Metric M5×0.8 female thread
- Tube Compatibility: Ø4mm (5/32") OD pneumatic tubing
- Max Operating Pressure: 1.0 MPa (145 psi)
- Temperature Range: -20℃ to 80℃ (NBR seals)/120℃ (POM seals)
- Flow Rate: 300 NL/min (at 0.5 MPa)
- Leakage Rate: ≤0.1 mL/min (under 0.5 MPa)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Weight: 118g ±2g (per complete assembly)
- Dimensions: 78mm(L) × 52mm(W) × 28mm(H) (individual unit)
- Package Contents: 10 pre-assembled units with integrated O-rings
Industrial-grade pneumatic quick connector featuring a dust-resistant sliding sleeve mechanism with positive click engagement. The 360° rotatable design enables flexible piping layouts while maintaining leak-free performance under dynamic conditions. Includes built-in strain relief for enhanced tubing retention.
Typical Applications:
- Modular pneumatic tool connections
- Automated material handling systems
- CNC machine tool coolant line interfaces
- Robotic end effector air supply coupling
- Packaging machine vacuum circuit junctions
Installation protocol:
Cut tubing ends square and deburr before insertion. For optimal seal life,
perform 2-3 full connection cycles before final installation. Maximum
allowable angular misalignment: 3°.
Compatibility note:
Not suitable for glycol-containing fluids or phosphate ester-based
lubricants. Flush system with dry air after each disconnection cycle.
