Airtac F-MG-CB Double Lug Bracket Assembly F-MG25CB
$5.54
Regular price
$13.04
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-MG25CB
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Product Category: Cylinder Accessories
Brand: AIRTAC
Series: F-MG-CB Double-Ear Mounting Bracket Complete Kit
Technical Specifications:
• Dual-lug design with reinforced structural integrity for cylinder stabilization
• Pre-assembled ISO-standard mounting solution with anti-corrosion surface treatment
• Compatible with pneumatic cylinders conforming to ISO 6431/VDMA 24562 standards
• Zinc-nickel plated carbon steel construction (EN10130 DC04 equivalent)
• Integrated M6 threaded fasteners with lock washers for vibration resistance
Application Scope:
Designed for precise axial alignment and rigid fixation of pneumatic cylinders in high-cycle automation systems. Optimized for reduced lateral load stress in robotic assembly and material handling equipment.
Installation guidance:
Apply 20-25N·m torque during screw tightening using cross-pattern sequence.
Use thread-locking compound on fasteners for high-cycle applications (>500,000 cycles).
Maintain 0.3-0.5mm clearance between bracket and cylinder end for thermal expansion.
AirTAC F-MG-CB Double Ear Mount Bracket Kit F-MG25CB Technical Details
- Model: F-MG25CB
- Type: Standard double ear mounting bracket kit
- Material: Aluminum alloy (6063-T5)
- Surface treatment: Anodized (black)
- Compatible cylinder series: MGPM/MGPY/MGQ 25mm bore
- Mounting hole spacing: 40±0.2mm (horizontal) × 36±0.2mm (vertical)
- Thread specifications: M6×1.0 (internal) / M8×1.25 (external)
- Max static load capacity: 980N (axial), 490N (radial)
- Max dynamic load: 588N (axial), 294N (radial)
- Operating temperature: -20℃ to 80℃
- Weight: 185g ±5g
- Dimensions: 65mm(L) × 48mm(W) × 25mm(H)
- Package includes: Bracket ×1, Hex socket screws ×4, Flat washers ×4
Heavy-duty dual pivot mounting solution designed for precise cylinder alignment in high-moment applications. Features CNC-machined mounting surfaces with 0.05mm flatness tolerance and self-lubricating brass bushings. Compatible with ISO 15552 mounting standards.
Typical Applications:
- Robotic arm joint articulation systems
- Vertical lift mechanisms in assembly lines
- Oscillating motion control in packaging machinery
- Precision positioning stages for optical equipment
- Vibration-damped installations in CNC tool changers
Installation guidance:
Apply 20-25N·m torque during screw tightening using cross-pattern sequence.
Use thread-locking compound on fasteners for high-cycle applications (>500,000 cycles).
Maintain 0.3-0.5mm clearance between bracket and cylinder end for thermal expansion.
| Property | Property Value |
|---|---|
| sku | F-MG25CB |
