Airtac F-MG-CB Double Lug Bracket Assembly F-MG40CB
AirTAC F-MG-CB Double-Ear Mounting Bracket Kit F-MG40CB Technical Details
- Model: F-MG40CB (Complete Bracket Assembly)
- Type: Universal double-ear mounting system
- Material: Aluminum alloy AL6061-T6
- Surface treatment: Anodized (black) + chromate plating
- Mounting hole spacing: 40±0.2mm (horizontal) × 32±0.2mm (vertical)
- Thread specifications: M5×0.8 internal threads (4 places)
- Load capacity: Max 120N static load (axial direction)
- Temperature resistance: -20℃ to 150℃ (continuous operation)
- Vibration resistance: 10-2000Hz, 20m/s² max
- Weight: 228g ±5g (including all fasteners)
- Dimensions: 72mm(L) × 54mm(W) × 28mm(H)
- Hardness: 75-80 HBW (bracket body)
- Fastener torque: 2.0-2.5N·m (M5 screws)
- Corrosion resistance: 96hrs salt spray test passed
Heavy-duty modular mounting solution with precision-machined alignment features. Includes pre-assembled bracket, M5×16 stainless steel screws (4pcs), and vibration-damping washers. The asymmetrical ear design allows 15° angular adjustment during installation while maintaining structural rigidity.
- Pneumatic cylinder mounting in automated assembly lines
- Sensor/encoder fixation on CNC machinery
- Vibration-sensitive equipment in semiconductor manufacturing
- Robotic arm component mounting with thermal expansion compensation
- Modular test fixture systems requiring quick reconfiguration
Installation protocol:
Apply thread-locking compound (medium strength) before final torque tightening.
Maintain 0.1-0.3mm gap between mating surfaces for thermal expansion.
Avoid galvanic corrosion by using isolation washers when mounting on dissimilar metals.
| Property | Property Value |
|---|---|
| sku | F-MG40CB |
