Airtac F-MG-FA Flange Mounting Plate Assembly Kit F-MG40FA
AirTAC F-MG-FA Flange Mounting Plate Kit F-MG40FA Technical Details
- Full model designation: F-MG40FA
- Material: 6063-T5 aluminum alloy (anodized finish)
- Mounting hole pattern: 4×M8 threaded holes (8.5mm clearance)
- Compatible cylinder series: MG40 standard bore models
- Surface hardness: HV 400±50 (hard anodized)
- Operating temperature: -20℃ to 80℃
- Static load capacity: 2,500N vertical / 1,800N horizontal
- Surface roughness: Ra ≤1.6μm
- Anti-corrosion protection: 96hr salt spray tested
- Weight: 1.2kg ±3% (including fasteners)
- Dimensions: 120mm(L) × 80mm(W) × 25mm(H)
- Mounting torque: 12-15N·m for M8 bolts
Precision-machined mounting solution for rigid cylinder fixation, featuring vibration-damping properties through its ribbed structural design. The electroless nickel-plated steel fasteners prevent galvanic corrosion with aluminum components. Includes 4×M8×25 flange bolts and spring washers pre-packed in anti-rust oil.
- Robotic arm end-effector mounting systems
- Pneumatic press vertical load support
- Conveyor line cylinder stabilization
- Multi-axis positioning stage assemblies
- Vibration-prone industrial machinery
Installation protocol:
Apply medium-strength thread locker (Loctite 243 recommended) on bolts before
torqueing. Align plate with cylinder's mounting groove within ±0.2mm tolerance
for optimal stress distribution. Re-torque after 24hrs of initial operation.
| Property | Property Value |
|---|---|
| sku | F-MG40FA |
