Airtac F-MG-LB Axial Retainer Assembly Kit F-MG32LB
AirTAC F-MG-LB Series Axial Mounting Bracket Kit: F-MG32LB Full Specifications
- Full model designation: F-MG32LB (Complete Kit)
- Compatible rail size: MG32 series linear guides
- Material: 6063-T5 aluminum alloy
- Surface treatment: Sandblasting + Anodized (Black)
- Mounting hole pattern: 4×M8 threaded holes (ISO 4762)
- Hole spacing: 60mm × 40mm (Longitudinal × Transverse)
- Static load capacity: 2,200N (Vertical direction)
- Dynamic load capacity: 1,500N (Vertical direction)
- Installation torque: 18-22N·m (M8 bolts)
- Thermal expansion coefficient: 23.6×10⁻⁶/℃
- Weight: 540g ±10g (including all mounting hardware)
- Dimensions: 98mm(L) × 78mm(W) × 24mm(H)
- Operating temperature: -20℃ to 120℃
- Vibration resistance: 5-2000Hz, 10G max (IEC 60068-2-6)
Precision-machined axial fixation solution for MG-series linear guide systems, featuring laser-etched alignment marks for simplified installation. The hardened stainless steel inserts (SUS304) in mounting holes prevent thread deformation during repeated maintenance. Includes 4×Class 10.9 M8×25mm hex socket bolts and spring washers.
- High-precision CNC router gantry reinforcement
- Automated warehouse stacker crane rails
- Lithium battery module assembly line positioning systems
- Semiconductor wafer handling robot base frames
- High-frequency reciprocating test equipment
Mounting protocol:
Apply 240-290N·cm torque in cross pattern sequence. Use 0.02mm feeler gauge
to verify rail-bracket contact. Compatible with ISO VG32-grade lubricants.
