Airtac F-MG-LB Axial Retainer Assembly Kit F-MG50LB
$11.13
Regular price
$18.63
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-MG50LB
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: Airtac
Series: F-MG-LB Axial Mounting Bracket Assembly Kit
The F-MG-LB series axial mounting bracket assembly kit provides a precision-engineered solution for cylinder stabilization and alignment in pneumatic systems. Designed with hardened steel construction and corrosion-resistant surface treatment, this complete mounting package ensures secure fixation while minimizing vibration transfer. Compatible with standard ISO cylinder profiles, it features pre-assembled components including mounting plates, tie rods, and fasteners for streamlined installation. The optimized structural design maintains cylinder parallelism under dynamic loads, making it ideal for high-cycle automation equipment requiring positional accuracy.
Mounting protocol:
Apply 25-30N·m torque during screw tightening using cross-pattern sequence.
Use included 0.1mm shim when axial play exceeds 0.15mm after installation.
AirTAC F-MG-LB Axial Mounting Bracket Kit F-MG50LB Technical Details
- Full model designation: F-MG50LB
- Material: Aluminum alloy 6063-T5 with hard anodized finish
- Compatible shaft diameter: Ø50mm (+0.05/-0.02mm tolerance)
- Static load capacity: 2,500N radial / 1,800N axial
- Dynamic load rating: 1,200N radial (at 0.5m/s linear speed)
- Mounting hole pattern: 4×M8 threaded holes (10mm depth) on 60mm PCD
- Surface hardness: HV 450-500
- Temperature range: -30℃ to 120℃ (continuous operation)
- Surface treatment: MIL-A-8625 Type III Class 2 compliant
- Weight: 1,150g ±3% (including mounting hardware)
- Dimensions: 78mm(W) × 68mm(H) × 54mm(D)
- Runout tolerance: ≤0.02mm (post-installation)
- Corrosion resistance: 500hrs salt spray test passed
Precision-engineered axial support solution for linear motion systems, featuring dual-row angular contact bearing configuration with preloaded spring washers. Includes corrosion-resistant M8×25mm mounting screws and alignment shims (0.1mm/0.2mm/0.5mm).
Installation Scenarios:
- Linear guide end support in CNC router Z-axis assemblies
- Ball screw fixation for automated packaging machinery
- Precision alignment in semiconductor wafer handling robots
- Support structure for 3D printer lead screw configurations
Mounting protocol:
Apply 25-30N·m torque during screw tightening using cross-pattern sequence.
Use included 0.1mm shim when axial play exceeds 0.15mm after installation.
Matched Components:
- Optimal pairing with AirTAC SHS45/SHS55 linear guides
- Compatible with ISO 3408-3 ball screws
- Requires MG-LUBE02 grease for high-speed applications (>2m/s)
| Property | Property Value |
|---|---|
| sku | F-MG50LB |
