Airtac F-MG-LB Axial Retainer Assembly Kit F-MG63LB
AirTAC F-MG-LB Axial Fixation Bracket Kit F-MG63LB Technical Details
- Full model designation: F-MG63LB (Complete axial fixation package)
- Material: Aluminum alloy 6063-T5 with hard anodized finish
- Surface treatment: Matte black oxidation (12-15μm thickness)
- Compatible shaft diameter: 63mm ±0.02mm tolerance
- Fixation method: Dual M8×1.25 hex socket head clamping bolts
- Anti-loosening design: Spring-loaded steel retention washers
- Mounting hole pattern: 4×Φ6.6 through holes (M6 screw compatible)
- Hole spacing: 78mm longitudinal × 45mm lateral (cross configuration)
- Axial load capacity: 3000N max (static), 1800N dynamic
- Radial stiffness: ≤0.01mm deformation at 1500N load
- Operating temperature: -20°C to +120°C (continuous)
- Weight: 1.8kg ±3% (including all hardware)
- Dimensions: 120mm(L) × 80mm(W) × 75mm(H)
- Surface roughness: Ra 0.8μm on clamping surfaces
- Compatibility: Designed for MGW/MGN series linear guide blocks
Precision-machined axial restraint system featuring vibration-damped clamping, specifically engineered for high-accuracy linear motion applications. The asymmetrical rib design enhances torsional rigidity while maintaining 75% weight reduction compared to steel counterparts. Includes pre-installed wear-resistant brass thread inserts and alignment dowels for simplified installation.
- CNC gantry axis end-stop reinforcement
- Industrial robot 4th/5th axis mechanical locking
- High-speed 3D printer Z-axis stabilization
- Semiconductor wafer handling equipment
- Automated optical inspection (AOI) systems
Mounting protocol:
Apply 18-22N·m torque using calibrated wrench during installation.
Perform thermal cycling (3× -10°C to 80°C) before critical applications.
Use shim stock (0.05mm max) if base flatness exceeds 0.1mm/m.
| Property | Property Value |
|---|---|
| sku | F-MG63LB |
