Airtac F-MG-SDB Hinged Bracket Assembly F-MG40SDB
AirTAC F-MG-SDB Series Hinge Bracket Kit F-MG40SDB Technical Details
- Full model designation: F-MG40SDB
- Bracket type: Reinforced pivot mount with integrated alignment grooves
- Material: ADC12 aluminum alloy (die-cast)
- Surface treatment: Hard anodized (25-30μm thickness)
- Mounting hole pattern: 40mm pitch (M8 threaded holes)
- Pivot bearing: Steel sleeve with PTFE lubrication layer
- Load capacity: Static 850N, Dynamic 420N
- Angular adjustment range: ±15° continuous rotation
- Operating temperature: -25℃ to 120℃ (dry environment)
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Corrosion resistance: 96hr salt spray test passed
- Weight: 0.68kg ±2%
- Dimensions: 82mm(L) × 54mm(W) × 38mm(H)
- Hardware included: M8×25 flange bolts (4pcs), anti-vibration washers
Precision-engineered mounting solution for pneumatic cylinder installations requiring angular adjustability. Features dual locking channels for secure positioning and corrosion-resistant construction. The self-lubricating pivot joint enables smooth rotation under load without maintenance.
- Robotic arm joint articulation systems
- Conveyor belt tension adjustment mechanisms
- Packaging machine rotary actuator mounts
- Automated welding equipment positioners
- Solar panel tracking system linkages
Installation protocol:
Apply 20-30N·m torque during bolt tightening. Use shim washers when mounting
on uneven surfaces. Lubricate pivot annually with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | F-MG40SDB |
