Airtac F-MI-LB Axial Fixing Bracket Assembly Kit F-MI12LB
AirTAC F-MI-LB Series Axial Mounting Bracket Kit F-MI12LB Technical Details
- Model: F-MI12LB (Complete Bracket Assembly)
- Type: Precision linear rail axial fixation kit
- Material: Aluminum alloy 6063-T5 with hard anodized surface (black)
- Radial load capacity: 1,200N (static)/800N (dynamic)
- Axial load capacity: 600N (static)/400N (dynamic)
- Compatible rail width: 12mm (for SHS/SBR12 series linear guides)
- Mounting hole spacing: 30±0.02mm (longitudinal) × 20±0.02mm (transverse)
- Fastener specifications: M4×8mm stainless steel countersunk screws (included)
- Surface roughness: Ra 0.8μm (mounting contact surfaces)
- Weight: 148g ±2g (complete assembly)
- Dimensions: 62mm(L) × 32mm(W) × 18mm(H) (excluding protrusions)
- Operating temperature: -20°C to 120°C (continuous use)
- Vibration resistance: 10-2000Hz, 20m/s² max
- Corrosion resistance: 96hr salt spray test compliant
CNC-machined positioning bracket featuring dual angular contact design for zero-backlash linear motion systems. The hardened mounting surfaces ensure ±0.01mm repeat positioning accuracy, with pre-loaded spring washers maintaining constant preload force. Includes vibration-resistant thread locker pre-applied on fasteners.
- High-speed pick-and-place robot end effectors
- Precision optical stage alignment systems
- Semiconductor wafer handling equipment
- Medical CNC biopsy needle guides
- 3D printer gantry reinforcement assemblies
Installation protocol:
Apply 0.5-0.8N·m torque using calibrated torque wrench.
Use 0.02mm feeler gauge to verify parallel alignment between
bracket base and rail mounting surface before final tightening.
| Property | Property Value |
|---|---|
| sku | F-MI12LB |
