Airtac F-MI-SDB Rear Hinge Bracket Assembly F-MI32SDB
AirTAC F-MI-SDB Rear Hinge Bracket Kit F-MI32SDB Technical Details
- Model: F-MI32SDB
- Type: Rear hinge mounting bracket kit (pre-assembled)
- Material: Aluminum alloy ADC12 with black anodized finish
- Compatible rail series: MI series linear guides (MI32 specific)
- Mounting hole spacing: 30±0.1mm (dual M6 threaded holes)
- Maximum dynamic load capacity: 850N
- Maximum static load capacity: 1,200N
- Operating temperature: -20°C to +80°C
- Surface hardness: HV 400±20
- Corrosion resistance: 500hr salt spray test passed
- Weight: 0.68kg ±2%
- Dimensions: 32mm(W) × 32mm(D) × 45mm(H)
- Protective coating: MIL-STD-171 anti-abrasion treatment
Precision-engineered mounting solution for MI series linear guide systems, featuring vibration-damped hinge mechanism with ±0.5° angular adjustment capability. Includes pre-installed Class 10.9 mounting bolts and anti-backlash washers. The anodized surface provides EMI shielding and prevents galvanic corrosion when used with steel components.
- High-speed CNC machine tool slide units
- Automated robotic arm positioning systems
- Precision optical stage assemblies
- Semiconductor wafer handling equipment
- Packaging line linear actuator installations
Installation protocol:
Apply 7-9N·m torque using calibrated wrench during assembly.
Use shim plates (0.1/0.2/0.5mm) for parallel alignment verification.
Lubricate hinge pivot with ISO VG32 hydraulic oil before operation.
