Airtac F-MI-TC End Cover Trunnion Bracket Assembly Kit F-MI10TC
$8.80
Regular price
$16.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-MI10TC
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AIRTAC
Series: F-MI-TC End Cover Trunnion Bracket Complete Assembly Kit
High-precision machined end cover trunnion mounting system engineered for ISO standard pneumatic cylinders. Features corrosion-resistant anodized aluminum construction with integrated pivot bearings for smooth angular adjustment. Pre-assembled kit includes mounting hardware and alignment shims to streamline cylinder installation in industrial automation applications. Compatible with AIRTAC MI/TC series cylinders for optimized load distribution and torsional stability.
Installation guidance:
Apply 2.0-2.5N·m torque during screw tightening. Use shim washers when mounting
on curved surfaces. Lubricate pivot points with ISO VG32-grade oil quarterly.
AirTAC F-MI-TC Trunnion Bracket Kit F-MI10TC Technical Specifications
- Model: F-MI10TC (Complete Kit)
- Type: End Cover Trunnion Bracket Assembly
- Material: Aluminum Alloy ADC12
- Surface Treatment: Anodized (Natural Silver)
- Bore Compatibility: Ø10mm Cylinders
- Static Load Capacity: Max. 300N (Radial Direction)
- Mounting Hole: M5×0.8 Thread (4 Places)
- Center Distance: 20mm (±0.1mm)
- Bracket Angle: 90° Fixed Position
- Operating Temp: -20℃ to 80℃ (No Ice Formation)
- Vibration Resistance: ≤10Hz @ 1.5mm Amplitude
- Weight: 82g ±2g
- Dimensions: 48mm(L) × 32mm(W) × 18mm(H)
- ISO Standard: 15552-compliant
- Included Hardware: 4×M5×8mm Hex Socket Screws (Class 12.9)
Precision-machined mounting solution for cylinder fixation, featuring anti-corrosion anodization and CNC-milled locating surfaces. Includes pre-installed wear-resistant brass threaded inserts for repeated disassembly. Designed for moment load distribution in multi-axis configurations.
Typical Applications:
- Robotic arm joint articulation points
- Pneumatic gripper mounting systems
- Linear actuator end-support configurations
- Packaging machine tooling plate installations
- Medical device lifting mechanism pivots
Installation guidance:
Apply 2.0-2.5N·m torque during screw tightening. Use shim washers when mounting
on curved surfaces. Lubricate pivot points with ISO VG32-grade oil quarterly.
