Airtac F-MI-TC End Cover Trunnion Bracket Assembly Kit F-MI12TC
AirTAC F-MI-TC End Cover Trunnion Bracket Kit F-MI12TC Technical Details
- Full model designation: F-MI12TC
- Bracket type: Dual-axis adjustable trunnion
- Material: Aluminum alloy ADC12 (zinc-aluminum composite)
- Surface treatment: Anodized black (alternative: nickel plating available)
- Mounting hole spacing: 12±0.2mm (center-to-center)
- Thread specifications: M6×1.0 internal threads (4 places)
- Load capacity:
- Static load: 150kg max
- Dynamic load: 90kg max @ ≤0.5m/s
- Operating temperature: -20℃ to +120℃ (continuous use)
- Weight: 450g ±5% (including fasteners)
- Dimensions: 65mm(L) × 40mm(W) × 25mm(H)
- Hardness: 80-85 HB (aluminum body)
- Corrosion resistance: 96hr salt spray test compliant
- Compatible cylinder series: MI series Ø12mm cylinders
Precision-machined mounting solution for linear actuators, featuring dual-axis angular adjustment (±3° vertical/horizontal) for misalignment compensation. The zinc-aluminum composite construction provides vibration damping while maintaining structural rigidity. Includes pre-installed stainless steel bushings and anti-loosening thread locker on all fasteners.
- Robotic arm joint articulation points
- Vibration-prone conveyor line actuators
- Multi-axis pneumatic positioning systems
- Packaging machinery with space constraints
- Laboratory automation equipment requiring precision alignment
Mounting protocol:
Apply 2.5-3.0N·m torque during installation using calibrated torque wrench.
Use shim washers when mounting on surfaces with roughness >Ra3.2.
Re-torque after 50 operating cycles.
Avoid side-impact loads exceeding 30N.
Not suitable for rotational speeds >120rpm.
Lubricate pivot points with ISO VG32 hydraulic oil quarterly.
