Airtac F-MI-TC End Cover Trunnion Bracket Assembly Kit F-MI40TC
AirTAC F-MI-TC End Cover Trunnion Bracket Kit F-MI40TC Technical Details
- Model: F-MI40TC (Complete Bracket Assembly)
- Compatible Cylinder Bore: Ø40mm Series
- Material: Aluminum Alloy ADC12 (Die Cast)
- Surface Treatment: Black Anodized (8-12μm)
- Mounting Thread: M8×1.25×15mm Deep (4 Holes)
- Bearing Type: Dual Ball Bearings (R6ZZ)
- Max Moment Load: 38N·m (Static), 19N·m (Dynamic)
- Axial Load Capacity: 1800N
- Rotation Angle: ±5° (Self-Alignment)
- Operating Temp: -20℃ to 80℃ (No Ice Formation)
- Weight: 480g ±2% (Including Fasteners)
- Dimensions: 82mm(L) × 52mm(W) × 44mm(H)
- Hardware Included: Class 8.8 M8×25 Hex Socket Screws (4pcs), Spring Washers
Precision-engineered trunnion mount solution for SDA/MAL series cylinders, featuring zero-backlash dual ball bearings and 3-axis adjustability. The hardened steel shaft (HRC58-62) integrates dust-resistant labyrinth seals, optimized for high-cycle rotational applications. Includes anti-vibration shim set for metal-to-metal installations.
- Robotic welding arm pivot joints (ISO 9409-1 compatible)
- 90° flipping mechanisms in assembly automation
- Oscillating conveyor drives in food processing lines
- Rotary clamps for CNC machine tooling
- Solar tracker azimuth/elevation drives
Mounting protocol:
Apply 20-30N·m torque using cross-pattern tightening sequence.
Lubricate bearing raceways with ISO VG32 equivalent grease quarterly.
Use 0.02mm feeler gauge to verify baseplate parallelism during installation.
| Property | Property Value |
|---|---|
| sku | F-MI40TC |
