Airtac F-PB-FA Front Flange Mounting Plate Assembled Kit F-PB12FA
$3.68
Regular price
$11.18
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-PB12FA
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: Airtac
Series: F-PB-FA Front Flange Mounting Bracket Complete Set
Engineered for precision alignment in pneumatic cylinder installations
Pre-assembled front flange configuration ensures stable mounting interface
CNC-machined bracket with standardized hole patterns for ISO cylinder compatibility
Includes mounting hardware and anti-vibration shim components
Surface-treated with anti-corrosion coating for industrial environments
Dual-bearing support design minimizes lateral load on cylinder rod
Installation note:
Use torque wrench for bolt tightening and apply thread-locking compound (not included).
Ensure cylinder rod axis is perpendicular to mounting surface within ±0.5° tolerance.
Brand: Airtac
Series: F-PB-FA Front Flange Mounting Bracket Complete Set
AirTAC F-PB-FA Series Front Flange Mounting Plate Kit (F-PB12FA)
- Model: F-PB12FA
- Type: Pre-assembled front flange mounting kit
- Material: Aluminum alloy ADC12
- Surface treatment: Anodized (natural silver)
- Mounting hole spacing: 30mm × 30mm (square pattern)
- Compatible cylinder series: SC/SU/SD 32-100mm bore sizes
- Mounting bolt specification: M6 × 12L (4 pcs included)
- Pilot tube ports: 2× M5 threaded (for sensor mounting)
- Weight: 0.38kg ±2%
- Dimensions: 82mm(L) × 82mm(W) × 16mm(H)
- Operating temperature: -20℃ to 80℃
- Vibration resistance: ≤49 m/s² (10-150Hz)
- Mounting torque: 5.4-6.0 N·m (for M6 bolts)
Precision-machined mounting solution for vertical cylinder installations requiring rigid support and alignment accuracy. Features integrated cable clamp slots and pre-installed mounting hardware. Compatible with ISO 15552 cylinder profiles.
Typical Applications:
- Pick-and-place robot end effectors
- Vertical press mechanisms in assembly lines
- Automated packaging machine stoppers
- Material handling system lifters
- Semiconductor equipment positioning stages
Installation note:
Use torque wrench for bolt tightening and apply thread-locking compound (not included).
Ensure cylinder rod axis is perpendicular to mounting surface within ±0.5° tolerance.
Compatible Accessories:
- Rod end brackets: F-MB12
- Adjustable stoppers: F-AS12
- Vibration dampers: F-VD6
| Property | Property Value |
|---|---|
| sku | F-PB12FA |
