Airtac F-PB-LB Axial Fixing Bracket Assembly Kit F-PB10LB
AirTAC F-PB-LB Axial Fixing Bracket Kit F-PB10LB Technical Details
- Model: F-PB10LB (Complete Bracket Assembly)
- Type: Precision-machined axial support bracket
- Material: Aluminum alloy 6063-T5
- Surface treatment: Anodized (black)
- Mounting hole pattern: M5/M6 dual-thread compatibility
- Load capacity: 10-50kg (dynamic)/100kg (static)
- Weight: 0.22kg ±5%
- Dimensions: 80mm(L) × 40mm(W) × 20mm(H)
- Operating temperature: -20℃ to 80℃
- Parallelism tolerance: ≤0.02mm
- Surface hardness: HV 80-100
- Corrosion resistance: 96hr salt spray test passed
- Vibration resistance: 5-2000Hz, 5G acceleration
- Mounting torque: 1.2-1.5N·m (M5), 2.4-3.0N·m (M6)
- IP rating: IP54 (standard configuration)
Precision alignment bracket designed for linear motion systems, featuring dual-plane mounting surfaces with micron-level flatness. The hardened contact surfaces ensure stable load distribution while the modular design allows quick installation on DIN rail systems. Includes pre-installed vibration-damping washers and stainless steel fasteners.
- Linear guide rail end-stop reinforcement
- Ball screw support in CNC machining centers
- 3D printer Z-axis stabilization
- Semiconductor wafer handling robots
- Medical imaging equipment slide rails
Installation protocol:
Clean mounting surfaces with IPA before assembly. Use torque wrench
for even force distribution. Apply thread-locking compound (medium strength)
on fasteners in high-vibration environments. Re-torque after 24hrs of initial operation.
