Airtac F-PB-LB Axial Fixing Bracket Assembly Kit F-PB6LB
AirTAC F-PB-LB Axial Fixing Bracket Kit F-PB6LB Technical Details
- Model: F-PB6LB (Complete Unit Kit)
- Material: 6063-T5 Aluminum Alloy (Anodized Finish)
- Compatible Rail: SBR/SBN/SBR20 Series Linear Guides
- Mounting Hole Pattern: 30mm × 15mm (Dual M4 Threaded Holes)
- Clamping Force: 120N Max (Axial Direction)
- Surface Hardness: HV 150-200
- Operating Temp: -20℃ to 120℃
- Weight: 85g ±2g (Including Fasteners)
- Dimensions: 38mm(L) × 24mm(W) × 18mm(H)
- Surface Treatment: Black Electrophoretic Coating (12-15μm)
- Vibration Resistance: 5-200Hz, 1.5mm Amplitude
- Corrosion Resistance: 96hrs Salt Spray Test (NSS)
Precision-machined axial retention bracket with integrated preload adjustment, designed for maintaining linear guide alignment under dynamic loads. Features dual hardened stainless steel M4×10 mounting screws (ISO 4762) and anti-loosening spring washers included. Electrophoretic coating ensures chemical resistance in humid environments.
- CNC machine tool Z-axis reinforcement
- 3D printer gantry stabilization systems
- Automated warehouse shuttle positioning
- Semiconductor wafer handling robots
- Laser cutting head support structures
Mounting protocol:
Clean rail surface with IPA before installation. Apply 0.5-0.6N·m torque
using calibrated tool. Verify parallel alignment with 0.02mm feeler gauge.
Re-torque after 48hrs of initial operation.
