Airtac F-PB-Y Connector Assembly Kit F-PB12Y
Brand: Airtac
Series: F-PB-Y Union Fitting Assembly Kit
This professional-grade pneumatic connector solution features standardized Y-shaped port configuration with precision-machined threads for leak-proof connectivity. Engineered for cylinder piping systems requiring 120° branch connections, the assembly includes pre-configured components with corrosion-resistant electrogalvanized finish. Compatible with ISO 6431/6432 cylinder interfaces, it supports working pressures up to 1.0MPa while maintaining φ8-φ16mm flow efficiency. The kit contains factory-tested union bodies, sealing elements, and mounting accessories for O.D.-based tube installations.
AirTAC F-PB-Y Series Quick Coupling Assembly Kit F-PB12Y Technical Details
- Model: F-PB12Y (Complete Assembly Kit)
- Type: Push-to-connect pneumatic quick coupling (plug + socket set)
- Material: Brass body with nickel plating
- Seal material: NBR (Nitrile) rubber
- Applicable tube OD: 12mm (metric series)
- Operating pressure: 0-1.0 MPa (145 psi)
- Burst pressure: ≥3.0 MPa (435 psi)
- Temperature range: -20℃ to +80℃
- Thread specification: G1/8" BSPP female threads (both ends)
- Flow rate: 350 NL/min (at 0.5 MPa)
- Leakage: <0.1 mL/min (under 0.5 MPa air pressure)
- Weight: 98g ±2g (complete pair)
- Dimensions (single unit): 42mm(L) × 24mm(W) × 24mm(H)
- Vibration resistance: 10-60Hz, 1.5mm amplitude
- Durability: 20,000+ connection cycles
Premium quick-disconnect coupling pair featuring one-touch tube connection with integrated check valve mechanism. The 30° push-lock design prevents accidental disconnection while allowing tool-free tube release. Nickel-plated brass construction ensures corrosion resistance in humid environments. Includes built-in dust cap for socket protection.
- Modular pneumatic system installations
- Mobile air compressor tool connections
- CNC machine tool coolant line interfaces
- Agricultural sprayer system quick-changes
- Robotic arm end effector swaps
Installation guidance:
For optimal performance, cut tubes square using proper tubing cutter.
Insertion depth should reach 23mm until audible click. Test pull strength
(≥50N required) after installation. Lubricate threads with PTFE tape
for airtight sealing.
Compatibility note:
Designed for polyurethane/nylon pneumatic tubing only. Not suitable
for fuel lines or chemical transfer. Maximum operating temperature
reduces to 60℃ when used with oil-mist lubricated systems.
| Property | Property Value |
|---|---|
| sku | F-PB12Y |
