Airtac F-RMS Axial Mounting Bracket Assembly F-RMS16LB
AirTAC F-RMS16LB Axial Rail Support Unit Technical Details
- Model: F-RMS16LB
- Type: Pre-assembled axial rail mounting block
- Material: Aluminum alloy 6063-T5
- Surface treatment: Black anodized (15-25μm thickness)
- Load capacity: 980N dynamic / 2,450N static
- Mounting hole size: M6 through holes (4 places)
- Hole spacing: 32mm longitudinal pitch
- Rail compatibility: SBR16/SBR16UU/HGR15 series
- Fastening torque: 5-6N·m (M6 screws)
- Operating temperature: -20℃ to 80℃
- Protection class: IP54 (standard sealing)
- Weight: 0.25kg ±5%
- Dimensions: 16mm(H) × 32mm(W) × 45mm(L)
Precision-machined axial support block with integrated mounting hardware, designed for rigid linear motion system installation. Features hardened contact surfaces (HRC 45-50) and pre-lubricated bushings for smooth assembly. Includes stainless steel SHMS6-16 locknuts and spring washers for vibration resistance.
- Linear module end support configurations
- 3D printer gantry axis stabilization
- Automated test equipment guide rail mounting
- Packaging machinery linear bearing pairs
- CNC tool carrier reinforcement
Installation protocol:
Use calibrated torque wrench for screw tightening. Apply LOCTITE 243 threadlocker.
Maintain rail parallelism within 0.05mm/m during assembly. Clean rail surfaces with
isopropyl alcohol before mounting.
| Property | Property Value |
|---|---|
| sku | F-RMS16LB |
| Bore Diameter | 16mm |
