Airtac F-RMS Axial Mounting Bracket Assembly F-RMS25LB
AirTAC F-RMS25LB Axial Fixation Bracket Complete Kit Specifications
- Model: F-RMS25LB
- Type: Linear guide axial fixation bracket assembly
- Material: Aluminum alloy 6063-T5 with hard anodized finish
- Load capacity: 2,500N static load / 1,800N dynamic load
- Mounting hole pattern: 25mm rail width compatible
- Bolt specifications: M6×12mm stainless steel (4 pcs included)
- Surface roughness: Ra 0.8μm on mating surfaces
- Mounting torque: 4.9-5.9 N·m (using included fasteners)
- Thermal expansion coefficient: 23.6×10⁻⁶/℃
- Operating temperature: -20℃ to 100℃
- Weight: 328g ±5g
- Dimensions: 78mm(L) × 42mm(W) × 34mm(H)
- Parallelism tolerance: ≤0.02mm on mounting surfaces
- Certification: ISO 6432 compliant, RoHS compliant
Precision-engineered axial fixation solution for linear motion systems, featuring integrated alignment pins and corrosion-resistant construction. The F-RMS25LB combines high rigidity with lightweight design, utilizing diamond-knurled clamping surfaces for vibration-resistant mounting. Includes pre-loaded wave washers to maintain consistent preload during thermal cycling.
- High-speed CNC machine tool slides
- Semiconductor wafer handling robots
- 3D printing gantry axis stabilization
- Automated optical inspection (AOI) equipment
- Medical linear actuator systems
- Packaging machine vertical axis support
Installation protocol:
Clean mounting surfaces with IPA before assembly. Torque bolts in cross pattern
using calibrated tool. Re-torque after 24hrs of operation. Avoid overtightening
to prevent rail deformation.
| Property | Property Value |
|---|---|
| sku | F-RMS25LB |
| Bore Diameter | <25 mm> |
